RTJ Flanges

RTJ Flanges

Vandan Alloys is a manufacturer, supplier, stockist and exporter of RTJ Flanges (Ring Type Joint Flanges) for high-pressure and critical piping applications. RTJ flanges use a precision-machined ring groove and a metallic ring gasket to provide a reliable pressure-tight joint when assembled correctly according to the applicable flange and piping requirements.

RTJ facing can be supplied on applicable flange configurations such as Weld Neck, Blind and other suitable flange types, depending on the standard, size, pressure class and project specification.

RTJ Flange Specifications

Product: RTJ Flanges

Type: Ring Type Joint Flanges / RTJ Facing Flanges

Material: Stainless Steel, Carbon Steel, Alloy Steel, Duplex, Super Duplex, Nickel Alloys and other specified materials

Standards: ASME B16.5, ASME B16.47 and applicable project specifications

Pressure Classes: Class 150, 300, 600, 900, 1500 and 2500, where applicable

Size Range: 1/2“ to 24” and larger sizes subject to applicable standard

Facing: Ring Type Joint (RTJ)

Bore: Standard or specified bore according to pipe dimensions and project requirements

Ring Groove: Machined RTJ groove according to applicable dimensional requirements

Drilling: Standard or customized bolt-hole drilling

Inspection: Visual and dimensional inspection as required

Certificate: EN 10204 Type 3.1 MTC available

Customization: Special bore, groove dimensions, drilling, facing and material grades available

RTJ Flange Material Grades

Vandan Alloys supplies RTJ Flanges in various materials and grades including:

Stainless Steel: 304, 304L, 316, 316L, 321, 347, 310, 310S and 904L

Carbon Steel: ASTM/ASME A105 and other specified grades

Alloy Steel: F11, F22 and other applicable alloy steel grades

Duplex Stainless Steel: 2205 / UNS S31803 / S32205

Super Duplex Stainless Steel: 2507 / UNS S32750 / S32760

Nickel Alloys: Nickel 200, Nickel 201, Monel 400, Inconel 625, Alloy 20, Hastelloy and other specified grades

Titanium: Grade 2, Grade 5 and other specified grades

RTJ Flange Design

RTJ Flanges incorporate a machined annular groove that receives a metallic ring gasket. During bolting, the ring gasket is seated within the groove to create the sealing arrangement.

The RTJ groove, flange dimensions, ring-gasket selection and bolt-up procedure must be compatible with the applicable standard and service conditions. Proper assembly is essential to achieve the intended sealing performance.

RTJ Ring Gasket Compatibility

RTJ flange assemblies are used with metallic ring-type joint gaskets selected according to the applicable groove configuration, pressure class, material and service requirements.

The ring gasket designation and dimensions should be verified against the applicable flange standard and project specification before ordering.

Pressure Classes

RTJ Flanges are commonly supplied for Class 300, 600, 900, 1500 and 2500 applications where the applicable standard permits RTJ facing.

Class 150 RTJ availability and configuration are dependent on the applicable standard, size and design specification and should be confirmed for the required application.

Pressure-class selection should consider design pressure, design temperature, material grade and the applicable piping code.

RTJ Flange Applications

RTJ Flanges are commonly selected for demanding applications including:

Oil & Gas Pipelines

Refineries

Petrochemical Plants

Chemical Processing

High-Pressure Piping

High-Temperature Service

Offshore & Onshore Facilities

Power Generation

Process Industries

Pressure Equipment Connections

Critical Process Piping

Hydrocarbon Processing Systems

Customized RTJ Flanges

Vandan Alloys can manufacture and supply RTJ Flanges according to customer drawings, applicable standards and project specifications.

Special requirements such as flange dimensions, bore, RTJ groove configuration, bolt-hole drilling, material grade, marking and inspection requirements can be considered after technical review.

Quality & Inspection

RTJ Flanges can be inspected for outside diameter, thickness, bore, bolt-hole dimensions, pitch circle diameter, RTJ groove dimensions, facing condition and overall dimensional accuracy.

Material Test Certificates including EN 10204 Type 3.1 MTC can be supplied as required. Third-party inspection can also be arranged according to customer specifications.

Why Choose Vandan Alloys?

RTJ Flanges Manufacturer in India

RTJ Flanges Exporter in India

Manufacturer & Supplier from India

Manufacturing Works in India

Wide range of material grades

High-pressure flange solutions

Precision-machined RTJ groove

Customized dimensions available

Dimensional inspection before dispatch

EN 10204 Type 3.1 MTC available

Export-quality packaging

Worldwide supply from Mumbai, India

Get a Quote

For RTJ Flanges, send us your NPS size, flange type, material grade, pressure class, bore, RTJ requirement, quantity and applicable standard.

Vandan Alloys supplies RTJ Flanges for high-pressure and critical industrial piping systems, with focus on dimensional accuracy, material compliance and dependable export supply.
